Length×Width×Height
(unladen)(mm)
6,965×2,545×4,000
7,115×2,545×4,090
6,965×2,545×4,000
6,965×2,545×4,000
6,965×2,545×3,950
6,965×2,545×3,950
6,915×2,545×3,400
Emission
Euro V
Euro Ⅲ
Euro V
Euro Ⅲ
Euro Ⅲ
Euro Ⅲ
Euro Ⅱ
Wheel base (mm)
3,300+1,400
3,375+1,400
3,300+1,400
3,300+1,400
3,300+1,400
3,300+1,400
3,300+1,350
Curb weight(kg)
10,500
10,500
10,500
10,000
10,000
9,680
8,750
Gross Vehicle Weight (kg)
41,870
41,870
41,870
24,870
24,870
29,808
22,500
Gross Combination Weight (kg)
110,000
110,000
110,000
80,000
80,000
60,000
60,000
Rated Power (hp) /（rpm）
517/2,100
520/1,900
517/2,100
517/2,100
517/2,100
435/1,900
460/1,900
Rated Torque (Nm)/（rpm）
2,200/1,100-1,500
2,550/1,000-1,400
2,200/1,100-1,500
2,200/1,100-1,500
2,200/1,100-1,500
2,150/1,100-1,400
2,110/1,100-1,500
